01012OT3H256T-S WEG AC Motors
Product Details
- Number of Poles 6 Pole
- Voltage 575 V
- Output Rating 10 HP
- Rated Speed 1180 rpm
- Flange Type Without
- Rated voltage 575 V
- Rated current 11.1 A
- Output 10 HP (7.5 kW)
- Breakdown torque 229 %
- Moment of inertia (J) 2.50 sq.ft.lb
- Design B
- Locked rotor time 61s (cold) 34s (hot)
- Frame 254/6T
- Rated torque 44.5 ft.lb
- No load current 5.86 A
- Temperature rise 80 K
- Duty Cycle Cont.(S1)
- Ambient temperature -20°C to +40°C
- Starting Method Direct On Line
- Mounting F-1
- Slip 1.67 %
- Number of Poles 6
- Rated speed 1180 rpm
- LRC 5.3x(Code G)
- Insulation Class F
- Frequency 60 Hz
- L. R. Amperes 58.9 A
- Locked rotor torque 210 %
- Altitude 1000 m.a.s.l.
- Enclosure IC01 - ODP
- Service factor 1.15
- Output rating 10 HP
- Terminal box¹ Left position
- Voltage 575 V
- Approx. weight³ 214 lb
- Number of poles 6
- Standard NEMA MG-1
- Noise level² 59.0 dB(A)
- Flange Without
- Rotation¹ Both (CW and CCW)
- Synchronous speed 1200 rpm
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
01012OT3H256T-S Related Documents
Manufacturer warranty
01012OT3H256T-S WEG
Get a quick Quote!
Request a quote, and we will send you price and availability within minutes.
Select Qty:
Average response time: 11 minutes
Fast Shipping & Delivery
We deliver nationwide and international
Secure Payment Processing
with money back guarantee
Warranty On All Parts
Manufacturer warranty
Responsive Customer Support
Let us know how we can help!
Need more details?
Feel free to chat with us
About the manufacturer
Advantage Electric Supply is an authorized WEG distributor, proudly offering a comprehensive range of products from this renowned global manufacturer specializing in electric motors, automation, and energy solutions. WEG stands as a leader in innovation and quality, providing advanced solutions that cater to various industrial needs. Their diverse product portfolio includes low and medium voltage ...
Recently viewed products
Relevant products
FAQ
Out if stock but available for backorder.
We're dedicated to getting your orders to you as fast as possible and offer different shipping options to make sure you get what you need on time.
We're fully committed to delivering quality you can trust. If something isn't quite right, you have 30 days to return it. And should a part be defective, our 1-year warranty ensures you're covered.
Rolled Steel NEMA Premium Efficiency 10 HP 6P 254/6T 3Ph 575 V 60 Hz IC01 - ODP - Foot-mounted
