01036OT3E213TC-S WEG AC Motors
Product Details
- Number of Poles 2 Pole
- Voltage 230/460 V
- Output Rating 10 HP
- Rated Speed 3535 rpm
- Flange Type C
- Output 10 HP (7.5 kW)
- Temperature rise 80 K
- Noise level² 66.0 dB(A)
- Slip 1.81 %
- Starting Method Direct On Line
- Output rating 10 HP
- Rated current 24.0/12.0 A
- Moment of inertia (J) 0.4651 sq.ft.lb
- Mounting F-1
- Voltage 230/460//190-220/380-415 V
- L. R. Amperes 163/81.6 A
- Breakdown torque 280 %
- Ambient temperature -20°C to +40°C
- Number of poles 2
- Frequency 60 Hz
- Locked rotor time 19s (cold) 11s (hot)
- Synchronous speed 3600 rpm
- Rated voltage 230/460 V
- Rated torque 14.9 ft.lb
- Duty Cycle Cont.(S1)
- Rotation¹ Both (CW and CCW)
- Number of Poles 2
- Locked rotor torque 200 %
- Altitude 1000 m.a.s.l.
- Terminal box¹ Left position
- Frame 213/5TC
- No load current 9.32/4.66 A
- Service factor 1.15
- Standard NEMA MG-1
- Rated speed 3535 rpm
- Design B
- Enclosure IC01 - ODP
- Flange C
- LRC 6.8x(Code H)
- Insulation Class F
- Approx. weight³ 126 lb
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
