01518ET3ER254TC-S WEG AC Motors
Product Details
- Number of Poles 4 Pole
- Voltage 230/460 V
- Output Rating 15 HP
- Rated Speed 1770 rpm
- Flange Type C
- Frame 254/6TC
- No load current 17.3/8.65 A
- Design B
- Enclosure IC411 - TEFC
- Approx. weight³ 225 lb
- Rated current 36.4/18.2 A
- Starting Method Direct On Line
- Output rating 15 HP
- Output 15 HP (11 kW)
- Rated torque 44.5 ft.lb
- Moment of inertia (J) 2.15 sq.ft.lb
- Ambient temperature -20°C to +40°C
- Slip 1.67 %
- Service factor 1.15
- Standard NEMA MG-1
- Rated speed 1770 rpm
- Locked rotor time 34s (cold) 19s (hot)
- Altitude 1000 m.a.s.l.
- Terminal box¹ Left position
- Number of Poles 4
- Degree of Protection IP55
- Voltage 230/460//190-220/380-415 V
- LRC 6.5x(Code G)
- Temperature rise 80 K
- Synchronous speed 1800 rpm
- Frequency 60 Hz
- Breakdown torque 300 %
- Duty Cycle Cont.(S1)
- Number of poles 4
- Rated voltage 230/460 V
- Locked rotor torque 250 %
- Mounting F-1
- Flange C
- L. R. Amperes 237/118 A
- Insulation Class F
- Rotation¹ Both (CW and CCW)
- Noise level² 68.0 dB(A)
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
