01536OP3VFP215JPV-S WEG AC Motors
Product Details
- Number of Poles 2 Pole
- Voltage 200/400 V
- Output Rating 15 HP
- Rated Speed 3525 rpm
- Flange Type C
- Slip 2.08 %
- Number of Poles 2
- Rated current 40.2/20.1 A
- No load current 16.9/8.46 A
- Starting Method Direct On Line
- Temperature rise 80 K
- Number of poles 2
- Frequency 60 Hz
- Breakdown torque 260 %
- Approx. weight³ 125 lb
- Frame 213/5JP
- Insulation Class F
- Voltage 200/400 V
- Rated voltage 200/400 V
- Service factor 1.15
- Rotation¹ Both (CW and CCW)
- Synchronous speed 3600 rpm
- L. R. Amperes 262/131 A
- Design B
- Enclosure IC01 - ODP
- Terminal box¹ Left position
- LRC 6.5x(Code G)
- Duty Cycle Cont.(S1)
- Standard NEMA MG-1
- Rated speed 3525 rpm
- Rated torque 22.3 ft.lb
- Noise level² 66.0 dB(A)
- Flange C
- Output 15 HP (11 kW)
- Locked rotor time 10s (cold) 6s (hot)
- Ambient temperature -20°C to +40°C
- Output rating 15 HP
- Locked rotor torque 190 %
- Altitude 1000 m.a.s.l.
- Moment of inertia (J) 0.4651 sq.ft.lb
- Mounting W-6
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
