02009ET3E324T-W22 WEG AC Motors
Product Details
- Number of Poles 8 Pole
- Voltage 230/460 V
- Output Rating 20 HP
- Rated Speed 880 rpm
- Flange Type Without
- Rated voltage 230/460 V
- Breakdown torque 220 %
- Rotation¹ Both (CW and CCW)
- Voltage 230/460//380 V
- LRC 5.0x(Code G)
- Altitude 1000 m.a.s.l.
- Noise level² 56.0 dB(A)
- Rated speed 880 rpm
- Moment of inertia (J) 9.37 sq.ft.lb
- Starting Method Direct On Line
- Number of poles 8
- Frequency 60 Hz
- Rated torque 119 ft.lb
- Degree of Protection IP55
- L. R. Amperes 283/142 A
- Locked rotor torque 190 %
- Ambient temperature -20°C to +40°C
- Output rating 20 HP
- Rated current 56.6/28.3 A
- Service factor 1.25
- Mounting F-1
- Slip 2.22 %
- Duty Cycle Cont.(S1)
- Insulation Class F
- Terminal box¹ Left position
- Frame 324/6T
- Locked rotor time 48s (cold) 27s (hot)
- Design B
- Standard NEMA MG-1
- Synchronous speed 900 rpm
- Output 20 HP (15 kW)
- Temperature rise 80 K
- Approx. weight³ 510 lb
- Number of Poles 8
- No load current 32.0/16.0 A
- Enclosure IC411 - TEFC
- Flange Without
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
