02018OP3E256JM WEG AC Motors
Product Details
- Number of Poles 4 Pole
- Voltage 230/460 V
- Output Rating 20 HP
- Rated Speed 1765 rpm
- Flange Type C
- Frame 256JM
- Locked rotor torque 229 %
- Altitude 1000 m.a.s.l.
- Terminal box¹ Left position
- Rated voltage 230/460 V
- Moment of inertia (J) 1.85 sq.ft.lb
- Enclosure IC01 - ODP
- Rated current 51.0/25.5 A
- Rated torque 59.5 ft.lb
- Degree of Protection IP23
- Synchronous speed 1800 rpm
- Standard NEMA MG-1
- LRC 5.6x(Code G)
- Temperature rise 105 K
- Rotation¹ Both (CW and CCW)
- Number of poles 4
- Slip 1.94 %
- Breakdown torque 250 %
- Approx. weight³ 240 lb
- Output 20 HP (15 kW)
- Ambient temperature -20°C to +40°C
- Duty Cycle Cont.(S1)
- Number of Poles 4
- No load current 21.8/10.9 A
- Noise level² 60.0 dB(A)
- Output rating 20 HP
- Frequency 60 Hz
- Locked rotor time 21s (cold) 12s (hot)
- Design B
- Flange C
- Rated speed 1765 rpm
- Service factor 1.15
- Mounting F-1
- L. R. Amperes 286/143 A
- Insulation Class F
- Starting Method Direct On Line
- Voltage 230/460 V
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
