02036OP3HFP254JPV-S WEG AC Motors
Product Details
- Number of Poles 2 Pole
- Voltage 575 V
- Output Rating 20 HP
- Rated Speed 3520 rpm
- Flange Type C
- Frame 254/6JP
- Number of Poles 2
- No load current 7.30 A
- Ambient temperature -20°C to +40°C
- Approx. weight³ 168 lb
- L. R. Amperes 114 A
- Locked rotor torque 180 %
- Output rating 20 HP
- Frequency 60 Hz
- Rated torque 29.8 ft.lb
- Enclosure IC01 - ODP
- Flange C
- Slip 2.22 %
- Locked rotor time 16s (cold) 9s (hot)
- Mounting W-6
- Synchronous speed 3600 rpm
- Rated voltage 575 V
- Service factor 1.15
- Terminal box¹ Left position
- Output 20 HP (15 kW)
- Design B
- Duty Cycle Cont.(S1)
- Rotation¹ Both (CW and CCW)
- LRC 6.0x(Code G)
- Temperature rise 80 K
- Noise level² 70.0 dB(A)
- Rated current 19.0 A
- Moment of inertia (J) 0.6974 sq.ft.lb
- Altitude 1000 m.a.s.l.
- Number of poles 2
- Rated speed 3520 rpm
- Breakdown torque 240 %
- Starting Method Direct On Line
- Insulation Class F
- Standard NEMA MG-1
- Voltage 575 V
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
