03030EP3OFP286TS-W22 WEG AC Motors
Product Details
- Number of Poles 2 Pole
- Voltage 380 V
- Output Rating 30 HP
- Rated Speed 2935 rpm
- Flange Type Without
- LRC 5.7x(Code F)
- Rotation¹ Both (CW and CCW)
- L. R. Amperes 231 A
- Service factor 1.15
- Terminal box¹ Left position
- Number of Poles 2
- Insulation Class F
- Duty Cycle Cont.(S1)
- Flange Without
- No load current 9.00 A
- Temperature rise 80 K
- Noise level² 70.0 dB(A)
- Synchronous speed 3000 rpm
- Rated voltage 380 V
- Locked rotor time 30s (cold) 17s (hot)
- Starting Method Direct On Line
- Output rating 30 HP
- Rated speed 2935 rpm
- Moment of inertia (J) 2.56 sq.ft.lb
- Mounting F-1
- Frequency 50 Hz
- Rated current 40.6 A
- Design B
- Altitude 1000 m.a.s.l.
- Approx. weight³ 399 lb
- Frame 284/6TS
- Breakdown torque 220 %
- Ambient temperature -20°C to +40°C
- Number of poles 2
- Slip 2.17 %
- Rated torque 53.7 ft.lb
- Degree of Protection IP55
- Voltage 380-400-415 V
- Output 30 HP (22 kW)
- Locked rotor torque 160 %
- Enclosure IC411 - TEFC
- Standard NEMA MG-1
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
03030EP3OFP286TS-W22 Related Documents
Manufacturer warranty
03030EP3OFP286TS-W22 WEG
Get a quick Quote!
Request a quote, and we will send you price and availability within minutes.
Select Qty:
Average response time: 11 minutes
Fast Shipping & Delivery
We deliver nationwide and international
Secure Payment Processing
with money back guarantee
Warranty On All Parts
Manufacturer warranty
Responsive Customer Support
Let us know how we can help!
Need more details?
Feel free to chat with us
About the manufacturer
Advantage Electric Supply is an authorized WEG distributor, proudly offering a comprehensive range of products from this renowned global manufacturer specializing in electric motors, automation, and energy solutions. WEG stands as a leader in innovation and quality, providing advanced solutions that cater to various industrial needs. Their diverse product portfolio includes low and medium voltage ...
Recently viewed products
Relevant products
FAQ
Out if stock but available for backorder.
We're dedicated to getting your orders to you as fast as possible and offer different shipping options to make sure you get what you need on time.
We're fully committed to delivering quality you can trust. If something isn't quite right, you have 30 days to return it. And should a part be defective, our 1-year warranty ensures you're covered.
W22 High Efficiency 30 HP 2P 284/6TS 3Ph 380-400-415 V 50 Hz IC411 - TEFC - Foot-mounted
