06018ET3E364TC-W22 WEG AC Motors
Product Details
- Number of Poles 4 Pole
- Voltage 230/460 V
- Output Rating 60 HP
- Rated Speed 1780 rpm
- Flange Type C
- Number of Poles 4
- Duty Cycle Cont.(S1)
- Number of poles 4
- LRC 6.2x(Code G)
- Temperature rise 80 K
- Synchronous speed 1800 rpm
- Rated voltage 230/460 V
- Locked rotor torque 220 %
- Starting Method Direct On Line
- Voltage 230/460//380 V
- L. R. Amperes 888/444 A
- Output 60 HP (45 kW)
- Service factor 1.25
- Standard NEMA MG-1
- Rated current 143/71.6 A
- Breakdown torque 240 %
- Rotation¹ Both (CW and CCW)
- Terminal box¹ Left position
- No load current 56.0/28.0 A
- Altitude 1000 m.a.s.l.
- Approx. weight³ 901 lb
- Slip 1.11 %
- Rated torque 177 ft.lb
- Design B
- Mounting F-1
- Flange C
- Rated speed 1780 rpm
- Locked rotor time 27s (cold) 15s (hot)
- Noise level² 67.0 dB(A)
- Frequency 60 Hz
- Insulation Class F
- Ambient temperature -20°C to +40°C
- Degree of Protection IP55
- Frame 364/5TC
- Moment of inertia (J) 22.4 sq.ft.lb
- Enclosure IC411 - TEFC
- Output rating 60 HP
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
