07536OP3H364JMV WEG AC Motors
Product Details
- Number of Poles 2 Pole
- Voltage 575 V
- Output Rating 75 HP
- Rated Speed 3555 rpm
- Flange Type C
- Rated voltage 575 V
- Slip 1.25 %
- Insulation Class F
- Service factor 1.15
- Flange C
- Rated speed 3555 rpm
- Moment of inertia (J) 6.81 sq.ft.lb
- Noise level² 80.0 dB(A)
- Frequency 60 Hz
- No load current 22.4 A
- Ambient temperature -20°C to +40°C
- Voltage 575 V
- LRC 6.3x(Code G)
- Degree of Protection IP23
- Approx. weight³ 761 lb
- L. R. Amperes 425 A
- Design B
- Temperature rise 80 K
- Terminal box¹ Left position
- Frame 364/5JM
- Duty Cycle Cont.(S1)
- Mounting W-6
- Output rating 75 HP
- Rated current 67.4 A
- Locked rotor time 27s (cold) 15s (hot)
- Enclosure IC01 - ODP
- Standard NEMA MG-1
- Number of Poles 2
- Locked rotor torque 180 %
- Rotation¹ Both (CW and CCW)
- Synchronous speed 3600 rpm
- Output 75 HP (55 kW)
- Rated torque 111 ft.lb
- Starting Method Direct On Line
- Breakdown torque 270 %
- Altitude 1000 m.a.s.l.
- Number of poles 2
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
