10263594 WEG AC Motors

Name: 10263594
Brand: WEG

Part#:10263594

Manufacturer:WEG

Category:AC Motors

Product Lifecycle:Discontinued

Product description

W21 NEMA Premium Efficiency 10 HP 2P 215Y 3Ph 208-230/460 V 60 Hz IC418 - TEAO - Pad mounted

Product Details

Number of Poles
2
Locked rotor time
36s (cold) 20s (hot)
Rated torque
14.9 ft.lb
Rotation¹
Both (CW and CCW)
Frequency
60 Hz
Moment of inertia (J)
0.7541 sq.ft.lb
Temperature rise
80 K
Voltage
208-230/460 V
Flange
Without
Rated speed
3530 rpm
Locked rotor torque
280 %
Enclosure
IC418 - TEAO
Output rating
10 HP
Rated voltage
208-230/460 V
Service factor
1.25
Synchronous speed
3600 rpm
Material (FERT)
50006910
Insulation Class
F
Degree of Protection
IP55
L. R. Amperes
227-208/104 A

Ambient temperature

-20°C to +40°C

Standard

NEMA MG-1

Frame

215Y

Design

Mounting

F-1

Slip

1.94 %

No load current

6.90-8.00/4.00 A

Altitude

1000 m.a.s.l.

Noise level²

72.0 dB(A)

Output

10 HP (7.5 kW)

Breakdown torque

350 %

Duty Cycle

Cont.(S1)

Number of poles

Terminal box¹

Left position

Rated current

25.5-23.4/11.7 A

LRC

8.9x(Code K)

Starting Method

Direct On Line

Approx. weight³

175 lb

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

10263594 Related Documents

Datasheet.pdf Drawings.pdf

Manufacturer warranty

10263594 WEG
