15036ET3G445TS-W22 WEG AC Motors
Product Details
- Number of Poles 2 Pole
- Voltage 460 V
- Output Rating 150 HP
- Rated Speed 3570 rpm
- Flange Type Without
- Rated voltage 460 V
- Locked rotor torque 180 %
- Duty Cycle Cont.(S1)
- Terminal box¹ Left position
- Insulation Class F
- Noise level² 81.0 dB(A)
- Standard NEMA MG-1
- LRC 6.5x(Code G)
- Rated speed 3570 rpm
- Ambient temperature -20°C to +40°C
- Flange Without
- L. R. Amperes 1060 A
- Rated torque 221 ft.lb
- Starting Method Direct On Line
- Voltage 460 V
- Number of Poles 2
- Locked rotor time 39s (cold) 22s (hot)
- Degree of Protection IP55
- Output rating 150 HP
- Rated current 163 A
- Moment of inertia (J) 39.1 sq.ft.lb
- Enclosure IC411 - TEFC
- Synchronous speed 3600 rpm
- Output 150 HP (110 kW)
- Breakdown torque 240 %
- Mounting F-1
- Number of poles 2
- Frequency 60 Hz
- Service factor 1.15
- Altitude 1000 m.a.s.l.
- Approx. weight³ 1749 lb
- Slip 0.83 %
- Design B
- Rotation¹ Both (CW and CCW)
- Frame 444/5TS
- No load current 41.0 A
- Temperature rise 80 K
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
