20012ST3HIE449T-W22 WEG AC Motors
Product Details
- Number of Poles 6 Pole
- Voltage 575 V
- Output Rating 200 HP
- Rated Speed 1185 rpm
- Flange Type Without
- L. R. Amperes 1157 A
- Rated voltage 575 V
- Design B
- Noise level² 70.0 dB(A)
- Rated current 190 A
- No load current 68.0 A
- Temperature rise 80 K
- Voltage 575 V
- Frequency 60 Hz
- Breakdown torque 240 %
- Starting Method Direct On Line
- Number of poles 6
- Slip 1.25 %
- Moment of inertia (J) 145 sq.ft.lb
- Ambient temperature -20°C to +40°C
- Synchronous speed 1200 rpm
- Frame 447/9T
- Degree of Protection IP56
- Approx. weight³ 2831 lb
- Number of Poles 6
- Locked rotor time 27s (cold) 15s (hot)
- Duty Cycle Cont.(S1)
- Rated speed 1185 rpm
- Rated torque 886 ft.lb
- Enclosure IC411 - TEFC
- Output rating 200 HP
- Output 200 HP (150 kW)
- Service factor 1.15
- Rotation¹ Both (CW and CCW)
- Flange Without
- LRC 6.1x(Code G)
- Locked rotor torque 220 %
- Mounting F-1
- Standard NEMA MG-1
- Insulation Class F
- Altitude 1000 m.a.s.l.
- Terminal box¹ Left position
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
20012ST3HIE449T-W22 Related Documents
Manufacturer warranty
20012ST3HIE449T-W22 WEG
Get a quick Quote!
Request a quote, and we will send you price and availability within minutes.
Select Qty:
Average response time: 11 minutes
Fast Shipping & Delivery
We deliver nationwide and international
Secure Payment Processing
with money back guarantee
Warranty On All Parts
Manufacturer warranty
Responsive Customer Support
Let us know how we can help!
Need more details?
Feel free to chat with us
About the manufacturer
Advantage Electric Supply is an authorized WEG distributor, proudly offering a comprehensive range of products from this renowned global manufacturer specializing in electric motors, automation, and energy solutions. WEG stands as a leader in innovation and quality, providing advanced solutions that cater to various industrial needs. Their diverse product portfolio includes low and medium voltage ...
Recently viewed products
Relevant products
FAQ
Out if stock but available for backorder.
We're dedicated to getting your orders to you as fast as possible and offer different shipping options to make sure you get what you need on time.
We're fully committed to delivering quality you can trust. If something isn't quite right, you have 30 days to return it. And should a part be defective, our 1-year warranty ensures you're covered.
W22 IEEE 841 NEMA Premium Efficiency 200 HP 6P 447/9T 3Ph 575 V 60 Hz IC411 - TEFC - Foot-mounted
