AM30248RQT Allied Moulded Products Electrical Enclosures
Part#:AM30248RQT
Manufacturer:Allied Moulded Products
Category:Electrical Enclosures
Product Lifecycle:Active
Product description
30"x24"x8" Control Series fiberglass wall mount enclosure assembly with raised hinged cover and stainless-steel quarter-turn latch
Product Details
- Width 24 in
- Height 30 in
- Depth 8 in
- Material Fiberglass
- Height: 30 in
- Depth: 8 in
- Usable Depth: 8.65 in
- Closure Type: Quarter Turn Latch
- Volume: 7114 cu. in.
- Mounting Description: Stainless steel feet fastened to back side brass inserts
- Width: 24 in
- Standards: UL 508A, UL 50 and UL 50E Types 1, 2, 3, 3R, 4, 4X, 12 and 13; File No. E120175Complies with: 1. EN / IEC 60204-1 and 60529 Type IP66 2. RoHS directive
- Country of Origin: United States of America
- UPC: 8533998420
- Carton Quantity: 1
- Carton Weight: 31 lbs
- Application: Enclose and protect electrial and electronic controls, instruments or components for indoor and outdoor applications. Especially well suited for extreme temperature and corrosive environments.
- Color: Gray (RAL 7035)
- Enclosure Type: Wall Cabinets
- Cover Type: Opaque
- UNSPSC: 39121324
- Brand: Control Series
- Material: ULTRAGUARD® Fiberglass reinforced polyester - compression molded SMC box and Cover
- Additional Materials: 316 stainless steel external hardware (hinges/latches/fasteners), 316 stainless steel mounting brackets, Plated carbon steel internal hardware, Brass inserts, Polyurethane (FIP) Formed-In-Place gasket system
- Features: Non-corrosive, non-conductive, light weight with lower installation cost, easy to modify and longer life cycle compared to steel. Rigid design with back panel inserts plus stainless steel mounting brackets and a gasket system encased in a continuous chann
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of AM30248RQT on Advantage Electric Supply is $906.89. Order now.
AM30248RQT Related Documents
Similar products from: Allied Moulded Products Electrical Enclosures
Manufacturer warranty
AM30248RQT Allied Moulded Products
$906.89
Your price can be lower.
Log in or Create account to check your discount
Backordered – place your order now, and we’ll take care of the rest
Select Qty:
$906.89
$906.89 each
Your order is guaranteed – we’ll keep you updated on delivery timelines
Fast Shipping & Delivery
We deliver nationwide and international
Secure Payment Processing
with money back guarantee
Warranty On All Parts
Manufacturer warranty
Responsive Customer Support
Let us know how we can help!
Need more details?
Feel free to chat with us
Compare AM30248RQT with other Electrical Enclosures products
Width
Height
Depth
Material
Height:
Depth:
Usable Depth:
Closure Type:
Volume:
Mounting Description:
Selected product
AM30248RQT
Allied Moulded Products
30"x24"x8" Control Series fiberglass wall mount enclosure assembly with raised hinged cover and stai...
Width24 in
Height30 in
Depth8 in
MaterialFiberglass
Height:30 in
Depth:8 in
Usable Depth:8.65 in
Closure Type:Quarter Turn Latch
Volume:7114 cu. in.
Mounting Description:Stainless steel feet fastene...
AM24200RL
Allied Moulded Products
24"x20"x10" Control Series fiberglass wall mount enclosure assembly with raised hinged cover and sta...
Width20 in
Height24 in
Depth10 in
MaterialFiberglass
Height:24 in
Depth:10 in
Usable Depth:10.65 in
Closure Type:Metal Snap Latch
Volume:-
Mounting Description:Stainless steel feet fastene...
AM1426
Allied Moulded Products
14"x12"x6" AM Series fiberglass wall mount enclosure assembly with 4-screw lift-off cover
Width12.26 in
Height14.14 in
Depth6.01 in
MaterialFiberglass
Height:14.14 in
Depth:6.01 in
Usable Depth:5.71 in
Closure Type:4-Screw Lift-Off
Volume:-
Mounting Description:Stainless steel feet fastene...
About the manufacturer
Advantage Electric Supply is an authorized Allied Moulded Products distributor, bringing you the highest quality industrial enclosures and electrical solutions designed to meet the diverse needs of your operations. Allied Moulded Products has been a leader in non-metallic enclosure manufacturing, offering a wide range of durable, innovative products that are essential for protecting electrical sys...
Recently viewed products
Relevant products
FAQ
What is the price of AM30248RQT?
Purchase the AM30248RQT from Advantage Electric Supply at the price of $906.89. Order today.
Out if stock but available for backorder.
We're dedicated to getting your orders to you as fast as possible and offer different shipping options to make sure you get what you need on time.
We're fully committed to delivering quality you can trust. If something isn't quite right, you have 30 days to return it. And should a part be defective, our 1-year warranty ensures you're covered.
30"x24"x8" Control Series fiberglass wall mount enclosure assembly with raised hinged cover and stainless-steel quarter-turn latch
