M16133LW-SL199 Alpha Wire Electronic Components
Part#:M16133LW-SL199
Manufacturer:Alpha Wire
Category:Electronic Components
Product Lifecycle:Active
Product description
Alpha M16133LW-SL199 PVC Control Cable for Stationary or Minimal Flex Applications - OPEN WIRE 16 Awg 33Conductor - Blue Conductor Insulation
Product Details
- WEIGHT LBS/MFT 0.533
- MANUFACTURER PART NUMBER M16133LW-SL199
- APPLICATION Factory equipment interconnects; Robotics; Automotive assembly equipment; Conveyor systems; Control panels; Automated pick-and-place systems; PLC-controlled equipment; Automated handling systems
- VOLTAGE 600V
- STATIC TEMPERATURE RATING -5°C to +90°C
- STANDARDS/APPROVALS CSA AWM CE LVD 2006/95/EC PLTC UL PLTC UL MTW UL TC-ER UL WTTC
- DYNAMIC TEMPERATURE RATING -25°C to +90°C
- ATTRIBUTES Oil and chemical resistanceUV resistanceDirect burialAbrasion resistanceEMI protectionStationary or minimal flex
- JACKET MATERIAL PVC
- NOMINAL OD (IN) 0.857
- NOMINAL OD (MM) 21.76
- SERIES Industrial Series M
- JACKET COLOR Slate
- CONDUCTOR MATERIAL Bare copper
- SHIELDING Unshielded
- NUMBER OF CONDUCTORS 33
- STRAND COUNT 26X30
- CONDUCTOR STRANDING Stranded
- CONDUCTOR COLOR Blue conductor insulation-numbered 1 green/yellow conductor 1 white-striped neutral
- AWG/GAUGE 16
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
