MP18165RW-YL199 Alpha Wire Electronic Components

Name: MP18165RW-YL199
Brand: Alpha Wire

MP18165RW-YL199 on Advantage Electric Supply

Part#:MP18165RW-YL199

Manufacturer:Alpha Wire

Category:Electronic Components

Product Lifecycle:Active

Product description

Alpha Wire Industrial Series P MP18165RW-YL199 18 AWG 65 Conductor - Unshielded - Yellow

Product Details

WEIGHT LBS/MFT
400
STANDARDS/APPROVALS
UL Approved CSA Approved CE Approved
MANUFACTURER PART NUMBER
MP18165RW-YL199
TEMPERATURE RANGE
-25°C to +90deg;C
ATTRIBUTES
UL Sunlight ResistantUL Oil Res. I/II10x bend radius static and dynamicSuitable for use in Class I Division 2 locations per Article 501 of the National Electric Code
VOLTAGE
600V
NOMINAL OD (IN)
1.41
NOMINAL OD (MM)
26.44
JACKET MATERIAL
Thermoplastic Elastomer (TPE)
CONDUCTOR COLOR
Red insulation-numbered 1 green/yellow conductor 1 white-striped neutral
AWG/GAUGE
18
SERIES
Industrial Series P
STRAND COUNT
19x30
CONDUCTOR MATERIAL
Bare copper
CONDUCTOR STRANDING
Stranded
JACKET COLOR
Yellow
SHIELDING
Unshielded
NUMBER OF CONDUCTORS
65

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

MP18165RW-YL199 Related Documents

Datasheet.pdf

Manufacturer warranty
