FAZ-B32/3 Eaton Electronic Components
Part#:FAZ-B32/3
Manufacturer:Eaton
Category:Electronic Components
Product Lifecycle:Active
Product description
Eaton FAZ supplementary protector,UL 1077 Industrial miniature circuit breaker - supplementary protector,Low levels of inrush current are expected,32 A,15 kAIC,Three-pole,3-5X /n,50-60 Hz,Standard terminals,B Curve
Product Details
- Number of Poles 3 Pole
- Current Rating 32 A
- Trip Curve B
- SCCR 10 kA
- UL Standard 1077
- UL CCN QVNU2
- UL File No. E177451
- Terminal Type Compression
- Warranty 1 year
- Application Suitable for applications where low levels of inrush current are expected
- Product Width 2 in
- Interrupt rating 15 kAIC
- Certifications CSA Std. C22.2 No.235 UL 1077 IEC 60947-2
- Number of poles Three-pole
- Product Weight .8 lb
- Circuit protection B curve
- EAN 4015082788506
- Frequency rating 50-60 Hz
- Catalog Number FAZ-B32/3
- Terminals Standard
- Product Name Eaton FAZ supplementary protector
- Catalog Notes For applications that require protection due to potential wiring damage at low fault conditions.
- Product Length/Depth 2.07 in
- Trip Type 3-5X /n
- Product Height 2.07 in
- Amperage Rating 32 A
- Type UL 1077 Industrial miniature circuit breaker - supplementary protector
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of FAZ-B32/3 on Advantage Electric Supply is $706.05. Order now.
