FAZ-C40/3N Eaton Electronic Components
Part#:FAZ-C40/3N
Manufacturer:Eaton
Category:Electronic Components
Product Lifecycle:Active
Product description
Eaton FAZ supplementary protector,UL 1077 Industrial miniature circuit breaker - supplementary protector,Medium levels of inrush current are expected,40 A,15 kAIC,Three-pole + neutral,5-10X /n,50-60 Hz,Standard terminals,C Curve
Product Details
- Number of Poles 3 Pole
- Current Rating 40 A
- Trip Curve C
- SCCR 5 kA
- UL Standard 1077
- UL CCN QVNU2
- UL File No. E177451
- Terminal Type Compression
- EAN 4015082789794
- Terminals Standard
- Catalog Number FAZ-C40/3N
- Interrupt rating 15 kAIC
- Catalog Notes Positioned for medium inrush startup currents to provide protection for small transformers and pilot devices.
- Number of poles Three-pole + N
- Product Weight 1 lb
- Circuit protection C curve
- Certifications UL 1077 IEC 60947-2 CSA Std. C22.2 No.235
- Product Length/Depth 2.76 in
- Frequency rating 50-60 Hz
- Product Name Eaton FAZ supplementary protector
- Type UL 1077 Industrial miniature circuit breaker - supplementary protector
- Product Width 3 in
- Amperage Rating 40 A
- Product Height 3.25 in
- Trip Type 5-10X /n
- Warranty 1 year
- Application Suitable for applications where medium levels of inrush current are expected
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
