PDD22G0035TFFJ Eaton Molded Case Circuit Breakers (MCCB)
Part#:PDD22G0035TFFJ
Manufacturer:Eaton
Category:Molded Case Circuit Breakers (MCCB)
Product Lifecycle:Active
Product description
Eaton Power Defense molded case circuit breaker, UL/CSA 240V Max, Frame 2, Two Pole, 35A, 65kA/240V, T-M (Fxd-Fxd) TU, Standard Line and Load (PDG2X2T100)
Product Details
- Product Name Eaton Power Defense molded case circuit breaker
- Circuit breaker frame type Complete breaker
- Warranty Eaton Selling Policy 25-000, one (1) year from the date of installation of the Product or eighteen (18) months from the date of shipment of the Product, whichever occurs first.
- Product Weight 2.041 kg
- Terminals Standard Line and Load
- Product Height 152.4 mm
- Rated operation voltage (Ue) at AC - max 240
- Voltage rating 240 V AC
- UPC 786679950388
- Product Length/Depth 88.9 mm
- Frame 2
- Voltage rating - max 240 V
- Class Class A
- Product Width 69.9 mm
- Number of poles Two-pole
- Trip Type T-M (Fxd-Fxd) TU
- Certifications UL 489 CSA
- Switch off technique Thermomagnetic
- Compliances RoHS Compliant
- Amperage Rating 35 A
- Catalog Number PDD22G0035TFFJ
- Interrupt rating 65 kAIC at 240 Vac
- Circuit breaker type PD2 UL/CSA Only
- Interrupt rating range 65 kAIC @240V (UL) 10 kAIC Icu @125 Vdc 10 kAIC Icu @250 Vdc
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
Manufacturer warranty
