PDF63N2500D4DM Eaton Molded Case Circuit Breakers (MCCB)
Part#:PDF63N2500D4DM
Manufacturer:Eaton
Category:Molded Case Circuit Breakers (MCCB)
Product Lifecycle:Active
Product description
Eaton Power Defense molded case circuit breaker, Globally Rated 100% UL, Frame 6, Three Pole, 2500A, 85kA/480V, PXR20D ARMS LSI w/ Modbus RTU, CAM Link and Relays, No Terminals (Metric Tapped Conductors)
Product Details
- Amperage Rating 2500 A
- Voltage rating 600 Vac
- Warranty Eaton Selling Policy 25-000, one (1) year from the date of installation of the Product or eighteen (18) months from the date of shipment of the Product, whichever occurs first.
- Circuit breaker frame type Complete breaker
- UPC 786679827949
- Number of poles Three-pole
- Product Length/Depth 247.65 mm
- Rated operation voltage (Ue) at AC - max 690
- Class Class A
- Catalog Number PDF63N2500D4DM
- Certifications CCC Marked IEC 60947-2
- Interrupt rating 85 kAIC at 480 Vac
- Terminals No Terminals
- Product Name Eaton Power Defense molded case circuit breaker
- Frame 6
- Communication Modbus RTU and CAM Link
- Product Width 393.7 mm
- Special features Modbus / Relays / CAM
- Switch off technique Electronic
- Compliances RoHS Compliant
- Interrupt rating range 150 kAIC Icu/ 100 kAIC Ics/ 330 kAIC Icm @240V (IEC) 150 kAIC @240V (UL) 65 kAIC Icu/ 40 kAIC Ics/ 143 kAIC Icm @480V Brazil (IEC) 70 kAIC Icu/ 50 kAIC Ics/ 154 kAIC Icm @440V (IEC) 35 kAIC Icu/ 25 kAIC Ics/ 73.5 kAIC Icm @525V South Africa (IEC) 70
- Product Weight 61.23 kg
- Voltage rating - max 600 V
- Trip Type PXR 20D LSI w/ARMS
- Product Height 393.7 mm
- Circuit breaker type PD6 Global (100% UL)
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
Manufacturer warranty
PDF63N2500D4DM Eaton
Get a quick Quote!
Request a quote, and we will send you price and availability within minutes.
Select Qty:
Average response time: 11 minutes
Fast Shipping & Delivery
We deliver nationwide and international
Secure Payment Processing
with money back guarantee
Warranty On All Parts
Manufacturer warranty
Responsive Customer Support
Let us know how we can help!
Need more details?
Feel free to chat with us
Compare PDF63N2500D4DM with other Molded Case Circuit Breakers (MCCB) products
Amperage Rating
Voltage rating
Warranty
Circuit breaker frame typ...
UPC
Number of poles
Product Length/Depth
Rated operation voltage (...
Class
Catalog Number
Selected product
PDF63N2500D4DM
Eaton
Eaton Power Defense molded case circuit breaker, Globally Rated 100% UL, Frame 6, Three Pole, 2500A,...
Amperage Rating2500 A
Voltage rating600 Vac
WarrantyEaton Selling Policy 25-000,...
Circuit breaker frame typeComplete breaker
UPC786679827949
Number of polesThree-pole
Product Length/Depth247.65 mm
Rated operation voltage (Ue) at AC - max690
ClassClass A
Catalog NumberPDF63N2500D4DM
Amperage Rating-
Voltage rating-
Warranty-
Circuit breaker frame type-
UPC-
Number of poles-
Product Length/Depth-
Rated operation voltage (Ue) at AC - max-
Class-
Catalog Number-
About the manufacturer
Advantage Electric Supply is an authorized Eaton distributor, dedicated to bringing you the highest-quality industrial solutions. Eaton, a global leader in power management and electrical components, specializes in a wide array of products designed to optimize operational efficiency and enhance safety across various industries. From electrical control systems to cutting-edge automation technologie...
About the Product Category
An MCCB, or Molded Case Circuit Breaker, is an electrical safety device that automatically disconnects electrical power when it identifies an overload, short circuit, or ground fault. Its purpose is to safeguard an electrical circuit from harm due to excessive current caused by an overload or short circuit.
Recently viewed products
Relevant products
FAQ
Out if stock but available for backorder.
We're dedicated to getting your orders to you as fast as possible and offer different shipping options to make sure you get what you need on time.
We're fully committed to delivering quality you can trust. If something isn't quite right, you have 30 days to return it. And should a part be defective, our 1-year warranty ensures you're covered.
Eaton Power Defense molded case circuit breaker, Globally Rated 100% UL, Frame 6, Three Pole, 2500A, 85kA/480V, PXR20D ARMS LSI w/ Modbus RTU, CAM Link and Relays, No Terminals (Metric Tapped Conductors)
