ST2771PGM Mersen Electronic Components

Product Details

• ROHS Compliant
  Yes
• Short Circuit Current Rating (SCCR)
  200 (most models) kA
• Connection/Terminal Type
  Box
• MCOV L-G
  320 V
• VPR L-G
  900 V
• Protection Modes
  L-G, L-N
• Number of Poles
  1-pole
• Number of Wires
  2 Wire
• Product Weight
  0.25 lb
• Sell Pack Height
  2.75 in
• UL SPD Type
  Type 1 Component Assembly
• Nominal Discharge Current (In) (8/20)
  20 kA
• Indication System Type
  Microswitch
• MOV Response Time
  <25 ns
• MCOV L-N
  320 V
• Sell Pack Quantity
  3 Each
• Nominal Operating Volt Rating (Un)
  270 V
• Indication System
  Yes
• Housing Material
  PET (Polyethelene Terphthalate)
• VPR L-N
  900 V
Product Height
2.7 in
Max Discharge Current : Imax (8/20)
50 kA per phase
System Configuration
Single Phase
Connection/Terminal Material
Zinc-Plated Steel
Product Width
0.7 in
Sell Pack Length
4.88 in
AC or DC
AC
Wiring range
#6 to #14 AWG
Installation Mounting
DIN Rail
Product Length
3.58 in
Sell Pack Width
2.88 in
