CSSG10RA Red Lion Industrial Automation Components
Part#:CSSG10RA
Manufacturer:Red Lion
Category:Industrial Automation Components
Product Lifecycle:Active
Product description
Red Lion CSSG10RA is an I/O unit designed for DIN rail mounting, suitable for operation in ambient air temperatures ranging from 0 to +50°C. It features 1 analog output that can be configured for 4-20mA, 0-20mA, or 0-10Vdc, and 3 digital outputs, with two being contact type NO and one being NO/NC SPDT contact type. The unit also includes 1 analog input for strain gauge with a 16-bits conversion rate. It functions as a single-loop PID module within the Modular multi-zone PID controllers series, facilitating connection to a base controller. The CSSG10RA supports a 15Hz analog input sampling rate, ensuring timely and accurate data processing for various automation applications.
Product Details
- Primary brand Red Lion
- Functions Single-loop PID module
- Frequency 15Hz analog input sampling rate
- Mounting mode DIN rail
- Digital outputs 2 x digital outputs (contact type NO) (OP1; OP2) 1 x digital output (NO/NC SPDT contact type) (OP3)
- Sub-range name Modular multi-zone PID controllers series (I/O modules)
- Analog inputs 1 x analog input (Strain gauge; 16-bits conversion)
- Compliant with standard(s) CE IEC 60068-2-6 (vibration) EN 61326-1 immunity to industrial locations EN 61010-1 EN 61010-2-030 EN 61010-2-201 UL Listed RoHS compliant ABS
- Product series / family name Process controllers
- Analog outputs 1 x analog output (4-20mA / 0-20mA / 0-10Vdc)
- Order code / Manufacturer SKU CSSG10RA
- Main function I/O unit
- Connection type Connection to base controller
- Ambient air temperature for operation 0...+50 °C
- Benefits Strain gage module for the modular controller series Hot-swappable replacement reduces downtime Auto addressing minimizes configuration time PID control with reduced overshoot Load cell / pressure / torque bridge inputs Software selectable low level input
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
CSSG10RA Related Documents
Similar products from: Red Lion Industrial Automation Components
Manufacturer warranty
CSSG10RA Red Lion
Get a quick Quote!
Request a quote, and we will send you price and availability within minutes.
Select Qty:
Average response time: 11 minutes
Fast Shipping & Delivery
We deliver nationwide and international
Secure Payment Processing
with money back guarantee
Warranty On All Parts
Manufacturer warranty
Responsive Customer Support
Let us know how we can help!
Need more details?
Feel free to chat with us
Compare CSSG10RA with other Industrial Automation Components products
Primary brand
Functions
Frequency
Mounting mode
Digital outputs
Sub-range name
Analog inputs
Compliant with standard(s...
Product series / family n...
Analog outputs
Selected product
CSSG10RA
Red Lion
Red Lion CSSG10RA is an I/O unit designed for DIN rail mounting, suitable for operation in ambient a...
Primary brandRed Lion
FunctionsSingle-loop PID module
Frequency15Hz analog input sampling r...
Mounting modeDIN rail
Digital outputs2 x digital outputs (contact...
Sub-range nameModular multi-zone PID contr...
Analog inputs1 x analog input (Strain gau...
Compliant with standard(s)CE IEC 60068-2-6 (vibration)...
Product series / family nameProcess controllers
Analog outputs1 x analog output (4-20mA / ...
508TX-A
