RSS32S1 Schmersal Key Switches
Part#:RSS32S1
Alt. Part#:101195365
Manufacturer:Schmersal
Category:Key Switches
Product Lifecycle:Active
Product description
RSS32S1 Schmersal - Keyed Selector Switch
Product Details
- Sealing type Membrane, Lip gaskets, Form seals
- Switching angle, right 90 °
- Diameter of the front ring 39.5 mm
- Ambient temperature, minimum +0 °C
- Standards EN 60947-5-1, IEC/EN 60947-1
- Number of plunger 2
- Mounting Mounting flange EFM
- Spacing 50 x 60 mm
- Gross weight 100 g
- Key withdrawal position Position I
- diameters for the cylinder lock 22 mm
- Restistance to shock 50 g
- Installation conditions (mechanical) arbitrarily
- Material of the cylinder lock Steel
- Number of switch positions 3
- Tightening torque of the screw 0.6 Nm
- Degree of protection IP65
- Versions Key - Selector switch - Front plate mounting
- Latching position right, left
- Diameter hole, with tolerance indication 22.3 + 0.4 mm
- Height with key inserted 58 mm
- Material of the front ring Aluminium
- Switching angle, left 90 °
- Diameter hole 22.3 mm
- Ambient temperature, maximum +75 °C
- Colour of the cylinder lock Silver
- Colour of the front ring Silver
- Latching Yes
- Fully insulated Yes
- Mechanical life, minimum 300,000 Operations
- Unlocking Rotating unlatcher
- Diameter total 39.5 mm
- Thickness of the front panel, maximum 6 mm
- Thickness, of the front panel, minimum 1 mm
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of RSS32S1 on Advantage Electric Supply is $244.00. Order now.
