.1618OS1B48-S WEG AC Motors
Product Details
- Number of Poles 4 Pole
- Voltage 115/208-230 V
- Output Rating 0.16 HP
- Rated Speed 1740 rpm
- Flange Type Without
- LRC 5.5x(Code P)
- Rotation¹ Both (CW and CCW)
- Terminal box¹ Without Terminal Box
- Rated current 3.46/1.91-1.73 A
- Design N
- Ambient temperature -20°C to +40°C
- Starting Method Direct On Line
- No load current 3.00/1.29-1.50 A
- Noise level² 50.0 dB(A)
- Output 0.16 HP (0.12 kW)
- Mounting F-1
- Voltage 115/208-230 V
- Slip 3.33 %
- Locked rotor torque 320 %
- Duty Cycle Cont.(S1)
- Frequency 60 Hz
- Moment of inertia (J) 0.0280 sq.ft.lb
- Service factor 1.35 (1.00 @ 208V)
- Synchronous speed 1800 rpm
- Standard NEMA MG-1
- L. R. Amperes 19.0/10.5-9.52 A
- Breakdown torque 300 %
- Altitude 1000 m.a.s.l.
- Number of Poles 4
- Rated torque 0.483 ft.lb
- Insulation Class F
- Output rating 0.16 HP
- Flange Without
- Rated speed 1740 rpm
- Enclosure IC01 - ODP
- Rated voltage 115/208-230 V
- Frame 48
- Locked rotor time 28s (cold) 16s (hot)
- Temperature rise 80 K
- Approx. weight³ 13.6 lb
- Number of poles 4
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
