10018ET3G405T-W22 WEG AC Motors
Product Details
- Number of Poles 4 Pole
- Voltage 460 V
- Output Rating 100 HP
- Rated Speed 1780 rpm
- Flange Type Without
- Slip 1.11 %
- Design B
- Mounting F-1
- Output rating 100 HP
- LRC 7.3x(Code H)
- Temperature rise 80 K
- Noise level² 68.0 dB(A)
- L. R. Amperes 825 A
- Ambient temperature -20°C to +40°C
- Number of poles 4
- Rated voltage 460 V
- Service factor 1.25
- Breakdown torque 260 %
- Voltage 460 V
- Number of Poles 4
- Locked rotor torque 240 %
- Starting Method Direct On Line
- Standard NEMA MG-1
- Output 100 HP (75 kW)
- Rated torque 295 ft.lb
- Altitude 1000 m.a.s.l.
- Terminal box¹ Left position
- Frequency 60 Hz
- Locked rotor time 23s (cold) 13s (hot)
- Degree of Protection IP55
- Flange Without
- Rated current 113 A
- Insulation Class F
- Rotation¹ Both (CW and CCW)
- Frame 404/5T
- No load current 38.0 A
- Duty Cycle Cont.(S1)
- Approx. weight³ 1175 lb
- Rated speed 1780 rpm
- Moment of inertia (J) 29.9 sq.ft.lb
- Enclosure IC411 - TEFC
- Synchronous speed 1800 rpm
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
