541419 WH005 Alpha Wire Electronic Components

541419 WH005 on Advantage Electric Supply
Alpha Wire

Part#:541419 WH005

Manufacturer:Alpha Wire

Category:Electronic Components

Product Lifecycle:Active

Product description

541419 WH005 - Alpha Wire THHN/THWN PVC/NYLON Building Wire - 14 AWG - 19/0.0147 Stranded Conductor - Bare Copper - 600V - White - 100ft

Product Details

  • STANDARDS/APPROVALS
    UL Approved
  • VOLTAGE
    600V
  • ADDITIONAL STANDARDS
    THHN|UL THWN|CA Prop 65
  • CONDUCTOR STRANDING
    Stranded
  • INSULATION MATERIAL
    PVC/Nylon
  • MANUFACTURER PART NUMBER
    541419 WH005
  • CONDUCTOR MATERIAL
    Bare copper
  • JACKET COLOR
    White
  • INSULATION THICKNESS (IN)
    0.016
  • NOMINAL OD (IN)
    0.116
  • AWG/GAUGE
    14
  • TEMPERATURE
    -40°F to +194°F-40°C to +90°C

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

541419 WH005 Related Documents

Datasheet.pdf

Manufacturer warranty

541419 WH005 Alpha Wire

Get a quick Quote!

Request a quote, and we will send you price and availability within minutes.

Select Qty:

Average response time: 11 minutes

Fast Shipping & Delivery

We deliver nationwide and international

Secure Payment Processing

with money back guarantee

Warranty On All Parts

Manufacturer warranty

Responsive Customer Support

Let us know how we can help!

Need more details?

Feel free to chat with us
