GRC416T33PWP09 Eaton Industrial Automation Components

Name: GRC416T33PWP09
Brand: Eaton

GRC416T33PWP09 on Advantage Electric Supply

Part#:GRC416T33PWP09

Manufacturer:Eaton

Category:Industrial Automation Components

Product Lifecycle:Active

Product description

GRC416T33PWP09 Eaton - Eaton Series G electronic molded case circuit breaker, RG-frame, GR, Digitrip 310 RMS, Electronic LS trip, Four-pole, 1600A, 600 Vac, 100 kAIC at 415 Vac, No term., 100% protected neutral pole, 800, 1000, 1250, 1600A adjustable rating plug

Product Details

Number of Poles
4
Voltage
600 volts
Length
9.75 inches
Frame
RG
Trip Type
Electronic LS
Height
20 inches
Amperage
1600 amperes
Weight
153 pounds
Terminal Type
Without Terminals

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
