GRC425T32PWP38 Eaton Industrial Automation Components

Name: GRC425T32PWP38
Brand: Eaton

GRC425T32PWP38 on Advantage Electric Supply

Part#:GRC425T32PWP38

Manufacturer:Eaton

Category:Industrial Automation Components

Product Lifecycle:Active

Product description

GRC425T32PWP38 Eaton - Eaton Series G electronic molded case circuit breaker, RG-frame, GR, Complete breaker, Digitrip 310 RMS, Electronic LSI trip, Four-pole, 2500A, 600 Vac, 100 kAIC at 415 Vac, Without terminals, 100% protected neutral pole, 2500A rating plug

Product Details

Number of Poles
4
Weight
197 pounds
Trip Type
Electronic LSI
Amperage
2500 amperes
Height
20 inches
Length
9.75 inches
Terminal Type
Without Terminals
Voltage
600 volts

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
