83020103 Mersen Electronic Components

Product Details

• Catalogue No.
  STPT2-30K750V-3PM
• Housing Material
  PA66 CT1; V-0
• VPR L-L
  5000 V
• Product Height
  90 mm
• Max Discharge Current : Imax (8/20)
  30kA
• Torque Rating
  4 N m
• MCOV L-L
  1500 V
• Product Length
  70 mm
• IEC SPD Type
  Type 2 / Class II
• Max. Back-Up Fuse
  125 A gG
• Uc (L-L)
  1500 V
• Product Width
  54 mm
• AC or DC
  AC
• Indication System Type
  Visual Indicator Microswitch / 3 pin dry contact
• MCOV L-G
  750 V
• Sell Pack Quantity
  1 EACH
• System Configuration
  TNC. IT
• Short Circuit Withstand (ISCCR)
  25 kA
• Uc (L-PEN)
  750 V
• Replacement Plug L-N
  SP2-30K750V
Sell Pack Length
105 mm
Nominal Discharge Current (In) (8/20)
15kA
Indication System
Yes
Up at In (L-PEN)
≤3.0 kV
Sell Pack Width
65 mm
Nominal Operating Volt Rating (Un)
400/690(IT)-690/1000(TNC) V
Number of Poles
3-Pole
VPR L-G
2500 V
Sell Pack Weight
0.4 kg
Short Circuit Current Rating (SCCR)
50 ... 100 kA
ROHS Compliant
Yes
MOV Response Time
25 ns
Product Weight
0.4 kg
Sell Pack Height
85 mm
