83020108 Mersen Electronic Components
Part#:83020108
Alt. Part#:8435297850663
Manufacturer:Mersen
Category:Electronic Components
Product Lifecycle:Active
Product description
SPD Type 2, 40kA, Uc320V, L-N, 1 Pole, 1 Module, Pluggable
Product Details
- Max Discharge Current : Imax (8/20) 40kA
- Number of Poles 1-Pole
- Product Height 90 mm
- ROHS Compliant Yes
- MOV Response Time 25 ns
- Sell Pack Width 23 mm
- IEC SPD Type Type 2 / Class II
- Max. Back-Up Fuse 125 A gG
- Product Width 18 mm
- Sell Pack Weight 0.134 kg
- System Configuration TT. TNS. TNC
- Short Circuit Current Rating (SCCR) 50 ... 100 kA
- Torque Rating 4 N m
- MCOV L-L 320
- Sell Pack Quantity 1 EACH
- Nominal Discharge Current (In) (8/20) 20kA
- Uc (L-N) 320 V
- VPR L-L 1000 V
- Nominal Operating Volt Rating (Un) 277 V
- Up at In (L-N) ≤1.5 kV
- Product Weight 0.134 kg
- AC or DC AC
- Indication System Type Visual Indicator
- Indication System Yes
- Product Length 70 mm
- Sell Pack Height 80 mm
- Catalogue No. STPT2-40K320V-1P
- Short Circuit Withstand (ISCCR) 25 kA
- Housing Material PA66 CT1; V-0
- Replacement Plug L-N SP2-40K320V
- Sell Pack Length 105 mm
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
