F1062789 Mersen Fuse Holders
Part#:F1062789
Alt. Part#:3605340603088
Manufacturer:Mersen
Category:Fuse Holders
Product Lifecycle:Active
Product description
F1062789 Mersen - Fuse Holder Modulostar® 600VAC 600VDC Class CC 4-Pole Visual Indicator
Product Details
- Number of Poles 4 Pole
- Current Rating 30 A
- Weight 186.14 g
- Voltage 600 VAC
- Rated voltage DC UL 600 V
- Indication System Yes
- Conventional Free Air thermal Current With Fuse-Links Ith 30 A
- Product Width 2.76 in
- Sell Pack Weight 1.587 lb
- Rated voltage AC UL 600 V
- Indication System Type Visual Indicator
- Number of Poles 4-Pole
- Comments Wiring tool : PZ2 or flat 5.5x1mm screw drivers recommended (max. diameter 6mm)
- Sell Pack Quantity 3 EACH
- Sell Pack Height 2.76 in
- Catalogue No. CUSCC4I
- Fuse Class Class CC
- Short Circuit Current Rating (SCCR) 200 kA
- Installation Mounting DIN rail acc. EN 60715
- Product Height 3.12 in
- Sell Pack Width 3.54 in
- ROHS Compliant Yes
- Ampere Rating 30 A
- Design Details CUSCC quadruple pole
- Torque Rating 17.7 lb-in
- Product Weight 0.529 lb
- Product Length 2.41 in
- Sell Pack Length 8.86 in
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of F1062789 on Advantage Electric Supply is $202.74. Order now.
About the product
F1062789 Mersen - Fuse Holder Modulostar® 600VAC 600VDC Class CC 4-Pole Visual Indicator | Mersen’s innovative Modulostar CUSCC fuse holders are finger-safe under IEC standards to an IP20 grade of protection, including fuse changing (with the flick of a finger).
Modulostar CUSCC fuse holders are available in 1, 2, 3 or 4 poles, with or without visual blown fuse indicator, in UL + IEC version.
Multi-pole units can also be field assembled by ordering pin-ties assembly kit. Made of tough and durable thermoplastic or thermoset material.
Recommended for use with Mersen Class CC fuse-links: ATDR, ATMR, and ATQR. | Features: *Modular design
*Compact design for space saving
*DIN rail mounting
*Degree of protection: IP20
*Finger safe
*Easy access to the fuse
*Lockable without accessory
*Sealable in closed & open position
*Optional visual blown fuse indicator
*Multi-pole assembly kit available
*Plastic material UL94V2 mini
*Plastic material R22HL2 for railway application
*Flame retardant materials with glow wire flammability index to 960°C | Application: *All circuits up to 600V for protection of motors, transformers, low voltage distribution, control circuits, drive protection
*Non-load operation
