11829385 WEG AC Motors
Product Details
- Frequency 60 Hz
- Rated speed 1130 rpm
- Rated voltage 208-230/460 V
- Locked rotor torque 280 %
- LRC 5.6x(Code G)
- Output 75 HP (55 kW)
- L. R. Amperes 1194-1080/540 A
- Slip 5.83 %
- Rated torque 349 ft.lb
- Breakdown torque 0 %
- Frame 444/5T
- Number of Poles 6
- Rated current 213-193/96.4 A
- No load current 89.6-81.0/40.5 A
- Starting Method Direct On Line
- Voltage 208-230/460 V
- Moment of inertia (J) 57.3 sq.ft.lb
- Noise level² 69.0 dB(A)
- Locked rotor time 79s (cold) 44s (hot)
- Duty Cycle Cont.(S1)
- Output rating 75 HP
- Enclosure IC01 - ODP
- Standard NEMA MG-1
- Insulation Class F
- Temperature rise 80 K
- Number of poles 6
- Service factor 1.00
- Mounting F-2
- Synchronous speed 1200 rpm
- Degree of Protection IP23
- Flange Without
- Design D
- Ambient temperature -20°C to +40°C
- Rotation¹ Both (CW and CCW)
- Altitude 1000 m.a.s.l.
- Approx. weight³ 1309 lb
- Terminal box¹ Right position
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
