PP0522 ifm Electronic Electronic Components

Product Details

• Protection class
  III
• Output signal
  switching signal
• Type of short-circuit protection
  yes (non-latching)
• Measuring range
  0...100 bar 0...1450 psi 0...10 MPa
• Pressure rating
  300 bar 4350 psi 30 Mpa
• Min. bursting pressure
  650 bar 9400 psi 65 MPa
• Process connection
  threaded connection G 1/4 external thread Internal thread:M5
• Conditionally suitable for
  use in gases at pressures > 25 bar only on request
• Application
  for industrial applications
• Media
  liquids and gases
• Medium temperature [°C]
  -25...90
• Operating voltage [V]
  9.6...36 DC; (communication mode: 18...32)
• Type of pressure
  relative pressure
• Current consumption [mA]
  < 45
• Reverse polarity protection
  yes
• Min. insulation resistance [MΩ]
  100; (500 V DC)
• Permanent current rating of switching output DC [mA]
  250
• Total number of outputs
  2
• Overload protection
  yes
• Number of digital outputs
  2
Power-on delay time [s]
0.3
Max. voltage drop switching output DC [V]
2
Number of inputs and outputs
Number of digital outputs: 2
Switching frequency DC [Hz]
170
Output function
normally open / closed; (configurable)
Electrical design
NPN
Short-circuit protection
yes
