RSS260-I2-ST-AS Schmersal Safety Switches

Product Details

• Active principle
  RFID
• Ensured switching distance ON, front
  10 mm
• Length of sensor
  18 mm
• Protection rating
  III
• AS-i Specification
  Safety-Slave
• AS-i Input, Channel 2
  Data bits DI 2 / DI 3 = dynamic code transmission
• AS-i Input module address
  0
• Standards
  IEC 61508, IEC 60947-5-3, EN ISO 14119
• Number of actuating directions
  2
• Ensured switching distance ON, side
  6 mm
• Ambient temperature, maximum
  +60 °C
• AS-i Operating voltage, minimum
  18 VDC
• AS-i Parameter bits, P0
  Actuator in
• Duration of risk, maximum
  200 ms
• Integral System Diagnostics, status
  Yes
• Ensured switch distance OFF Sar, lateral
  15 mm
• Degree of protection
  IP65 to EN 60529, IP67 to EN 60529
• Overvoltage category
  III
• AS-i Operating voltage AS-i maximum
  31.6 VDC
• AS-i, IO-Code
  0x0
AS-i Parameter bits, P1
Enabling inhibit (tamper protection time) active (FID))
Coding level according to ISO 14119
High
Gross weight
55 g
Switch distance Sn
12 mm, 9 mm (in case of approach from side)
Storage and transport temperature, minimum
-25 °C
Switching frequency, maximum
1 Hz
AS-i, ID-Code
0xB
AS-i Parameter bits, P3
Internal device error (FID)
Time to readiness, maximum
2,000 ms
Safety functions
Yes
Terminal Connector
Connector M8, 4-pole, A-coded
Width of sensor
40 mm
Degree of pollution to VDE 0100
3
AS-i, ID-Code1
0xF
AS-i Parameter bits, P2
Enabling inhibit (tamper protection time) active (FID)
Rated insulation voltage Ui
32 VDC
AS-i Version
V 2.1
AS-i Input, Channel 1
Data bits DI 0 / DI 1 = dynamic code transmission
Reaction time, maximum
100 ms
Coding
Yes
Height of sensor
29.5 mm
Resistance to vibrations to EN 60068-2-6
10 … 55 Hz, amplitude 1 mm
Rated impulse withstand voltage Uimp
0.8 kV
AS-i Profile
S-0.B.F.E
Note (AS-i Parameter bits)
Set the parameter outputs to "1111" (0xF), FID: periphery error
general information
Individual coding, multiple teaching
Repeat accuracy R R
0.5 mm
Ambient temperature, minimum
-25 °C
Storage and transport temperature, maximum
+85 °C
AS-i Current consumption, maximum
100 mA
AS-i Outputs, DO 0 … DO 3
No Function
Enclosure material
Thermoplastic hotmelt
Hysteresis (Switch distance), maximum
2 mm
Ensured switching distance OFF, front
18 mm
Restistance to shock
30 g / 11 ms
Note (AS-i Operating voltage)
Protection against polarity reversal
AS-i, ID-Code2
0xE
Note (AS-i Input module address)
Preset to address 0, can be changed through AS-interface bus master or hand-held programming device
