ID0039 ifm Electronic Electronic Components
Part#:ID0039
Manufacturer:ifm Electronic
Category:Electronic Components
Product Lifecycle:Active
Product description
Inductive sensor, Very long sensing range, Output function: normally open, Sensing range [mm]: 50, Housing: rectangular, Dimensions [mm]: 92 x 80 x 40
Product Details
- Overload protection yes
- Operating voltage [V] 20...140 AC / 10...140 DC
- Minimum load current [mA] 5.5
- Output function normally open
- Permanent current rating of switching output AC [mA] 450
- Protection class I
- Max. leakage current [mA] 1.7 (140 V AC/DC)
- Housing rectangular
- Max. voltage drop switching output DC [V] 6
- Type of short-circuit protection yes (non-latching)
- Reverse polarity protection yes
- Short-time current rating of switching output [mA] 2200; (20 ms / 0,5 Hz)
- Dimensions [mm] 92 x 80 x 40
- Max. voltage drop switching output AC [V] 6
- Switching frequency DC [Hz] 25
- Sensing range [mm] 50
- Permanent current rating of switching output DC [mA] 450
- Short-circuit protection yes
- Frequency AC [Hz] 47...63
- Switching frequency AC [Hz] 25
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
